description
Engine
Bore x Stroke (mm)
57.4×57.8
Compression ratio
10.3:1
Cooling system
Air-cooled
Displacement (cc)
149.6
Fuel system
EFI
Ignition
TCI
Lubrication system
Pressure splash lubrication
Max. torque
10.5N·m/6500 r/min
Power
7.2kW at 7000 r/min
Starter
Electric & Kick
Type
1-cylinder/4-stroke
Transmission
Clutch type
Automatic
Final drive
Belt
Gearbox
Automatic CVT
Chassis
Front brakes
Disc
Front brakes diameter (mm)
185
Front suspension
Telescopic forks
Front suspension travel (mm)
75
Front tIre
120/70-12
Front wheel
Alloy
Rear brakes
Drum
Rear brakes diameter (mm)
130
Rear suspension
Telescopic coil spring oil damped
Rear suspension travel (mm)
60
Rear tIre
120/70-12
Rear wheel
Alloy
Dimensions & Weights
Battery
12V7Ah
Dry weight (kg)
107
Fuel capacity (L)
5.6
Ground clearance (mm)
130
Max. load (kg)
150
Overall height (mm)
1150
Overall length (mm)
1920
Overall width (mm)
680
Seat height (mm)
790
Top speed (km/h)
90
Wheelbase (mm)
1360
