Engine Information
|
||
EPA and CARB certificated
|
||
Engine type:
|
4-stroke, single cylinder, air cooled
|
|
Displacement:
|
169cc
|
|
Max HP:
|
11hp/8000rpm
|
|
Max torque:
|
8.1 lb ft/6000rpm
|
|
Bore x stroke:
|
2.4x2.28 inches
|
|
Climbing ability:
|
18 degrees
|
|
Engine oil:
|
SAE 15W-40
|
|
Ignition:
|
C.D.I for 200 XRX & ECU for 200E XRX
|
|
Starting system:
|
Electric
|
|
Battery:
|
12V 10Ah
|
|
Carburetor brand:
|
Deli (Vacuum film)
|
|
|
|
|
General Information
|
||
Clutch:
|
Automatic CTV with reverse
|
|
Driveline / Driving wheel:
|
Chain / Dual wheel drive
|
|
Suspension, F / R:
|
Double A-arm / swing-arm
|
|
Brakes, F / R:
|
Both hydraulic brakes, Disc
|
|
Tires, F / R:
|
20x7-8 / 22x10-10
|
|
Wheel:
|
Aluminum
|
|
Fuel capacity:
|
2.25 gal
|
|
Weight, G.W. / N.W.:
|
573 / 485 lbs
|
|
Max load:
|
500 lbs
|
|
Dimension Information
|
||
Wheelbase:
|
59 inches
|
|
OA L x W x H:
|
85x53.1x57.5 inches
|
|
Height to seat:
|
13.8 inches
|
|
Min ground clearance:
|
6.7 inches
|
|
Pedal to seat back distance:
|
39'' to 43''
|
|
Polished Aluminum wheel
|
Digital speedometer/odometer
|
|
Top hunting lights
|
Aluminum side mirrors
|
|
Turn signals
|
Sporting steering wheel
|
|
Electric start with kill switch
|
Fully automatic with reverse, high performance GY6 engine with internal reverse set up
|
|
Adjustable steering wheel
|
Large tires with 20X7-8 in the front and 22X10-10 in the back
|
|
Four-point safety seatbelt
|
Individual sporting seats
|
|
Polished stainless steel muffler
|
High-low beam head light
|
|
Bikini sunshade top
|
Adjustable driver seat: pedal to seat back adjustable from 39'' to 43''
|
|
Central rear view mirror
|
Heavy duty front and rear shock absorber
|
|
Rack and pinion steering wheel
|
Front and rear hydraulic disc brake
|
|
4-point rear swing arm
|
Parking brake
|
|
4-wheel fenders
|
Trailer hitch
|
|
Large rear utility rack
|
Large gas tank
|
|
|
