STANDARD FEATURES
• 493cc 32 HP EFI 4 stroke engine
• Reaches speeds up to 49 MPH
• On demand 4WD with 25 in. AT tires
• Electronic Power Steering, 3,000 lbs. Winch
• Passenger Backrest
• LED Lights
• Front Bumper
• Hand Guards
• AND MORE!
• 493cc 32 HP EFI 4 stroke engine
• Reaches speeds up to 49 MPH
• On demand 4WD with 25 in. AT tires
• Electronic Power Steering, 3,000 lbs. Winch
• Passenger Backrest
• LED Lights
• Front Bumper
• Hand Guards
• AND MORE!
DIMENSIONS
• VEHICLE SIZE (L X W X H): 91 IN X 46 IN X 52 IN
• WHEELBASE: 57.5 IN
• GROUND CLEARANCE: 10.5 IN
• TOWING CAPACITY: 1,200 LBS
• FUEL CAPACITY: 3.8 GALLONS
• SEAT HEIGHT: 38 IN
• DRY WEIGHT: 799 LBS
• WHEELBASE: 57.5 IN
• GROUND CLEARANCE: 10.5 IN
• TOWING CAPACITY: 1,200 LBS
• FUEL CAPACITY: 3.8 GALLONS
• SEAT HEIGHT: 38 IN
• DRY WEIGHT: 799 LBS
4 STROKE SINGLE CYLINDER
ENGINE TYPE: FOUR STROKE SINGLE CYLINDER SOHC
DISPLACEMENT: 493CC
HORSEPOWER: 33 HP
COOLING: LIQUID COOLED
TRANSMISSION/FINAL DRIVE: AUTOMATIC R/N/L/H, SHAFT DRIVE
DRIVE SYSTEM: ON DEMAND 2WD/4WD, LOCKING DIFFERENTIAL
FUEL SYSTEM: ELECTRONIC FUEL INJECTION(EFI)
DISPLACEMENT: 493CC
HORSEPOWER: 33 HP
COOLING: LIQUID COOLED
TRANSMISSION/FINAL DRIVE: AUTOMATIC R/N/L/H, SHAFT DRIVE
DRIVE SYSTEM: ON DEMAND 2WD/4WD, LOCKING DIFFERENTIAL
FUEL SYSTEM: ELECTRONIC FUEL INJECTION(EFI)
CHASSIS
• FRONT SUSPENSION: MACPHERSON INDEPENDENT
• REAR SUSPENSION: INDEPENDENT DUAL A-ARM
• FRONT TIRES: AT 25X 8-12
• REAR TIRES: AT 25X 10-12
• FRONT BRAKES: HYDRAULIC DISK BRAKES
• REAR BRAKES: HYDRAULIC DISK BRAKES
• REAR SUSPENSION: INDEPENDENT DUAL A-ARM
• FRONT TIRES: AT 25X 8-12
• REAR TIRES: AT 25X 10-12
• FRONT BRAKES: HYDRAULIC DISK BRAKES
• REAR BRAKES: HYDRAULIC DISK BRAKES
ADDITIONAL FEATURES
ASSEMBLED IN TEXAS, USA
INSTRUMENTATION: DIGITAL DISPLAY, SPEEDOMETER,
ODOMETER, TACHOMETER, HOUR METER,
GEAR INDICATOR, 4WD INDICATOR,
DIFFERENTIAL LOCK INDICATOR,
DUAL TRIP METER,
HEADLIGHTS (HIGH/LOW),
TURN SIGNALS, FUEL GAUGE,
HI-TEMP, USB
INSTRUMENTATION: DIGITAL DISPLAY, SPEEDOMETER,
ODOMETER, TACHOMETER, HOUR METER,
GEAR INDICATOR, 4WD INDICATOR,
DIFFERENTIAL LOCK INDICATOR,
DUAL TRIP METER,
HEADLIGHTS (HIGH/LOW),
TURN SIGNALS, FUEL GAUGE,
HI-TEMP, USB
