description
| Engine Information | |
| Engine type: | 4-stroke, single cylinder, air cooled |
| Displacement: | 200cc |
| Max HP: | 6.3hp/3600rpm |
| Max torque: | 9.6 lb ft/2500rpm |
| Bore x stroke: | 2.6 x 2.1 inches |
| Max speed: | 25mph |
| Climbing ability: | 12 degrees |
| Ignition: | C.D.I |
| Starting system: | Manual Pull Start |
| Battery: | 12V 9Ah only by Electric Start |
| Carburetor brand: | JF (RX) |
| Engine oil: | SAE 15W-40 |
| General Information | |
| Clutch: | Automatic CVT |
| Driveline / Driving wheel: | Chain / Dual wheel drive |
| Suspension, F / R: | - / Double Oil Damped Shock |
| Brakes, F / R: | No / Hydraulic brake, Disc |
| Tires, F / R: | 145/70-6 / 16x6-8 |
| Fuel capacity: | 1 gal |
| Weight, G.W. / N.W.: | 386 / 330 lbs |
| Max load: | 400 lbs |
| Dimension Information | |
| Wheelbase: | 48.4 inches |
| OA L x W x H: | 67x43.3x51.2 inches |
| Height to seat: | 10.2 inche |
| Min ground clearance: | 2.8 inches |
| Pedal to seat back distance: | 31 |
