ENGINE INFORMATION |
|
| • EPA Certificated • Engine Type: 4-stroke, single cylinder, air and oil cooled • Displacement: 177.3cc • Compression Ratio: 8.8:1 • Max HP: 9.5HP • Bore & Stroke: 62.5X57.8 mm • Max Torque and Crankshaft Speed: 11.0/4500 N.m/(RPM) |
• Nominal Power and Crankshaft Speed: 6.5/6500 kw/(RPM) • Max Speed: 25mph • Climbing Ability: 30 degrees • Ignition: C.D.I • Starting System: Electric • Battery: 12V 9Ah • Carburetor Brand: Deli • Engine Oil: SAE 15W/40 |
GENERAL INFORMATION |
|
| • Transmission: Auto, L-H-N-R • Drive Train: Shaft Drive; 2 WD: • Drive Mode: Rear Shaft Drive, Rear differential • Suspension, F/R: Front MacPherson, Rear Dual A-ARM • Brakes, F / R: Both hydraulic brakes, Disc |
• Tires, F / R: 24 x 8-12 / 24 x 8-12 • Fuel Tank Capacity: 4.8 gallons • Wheels: Aluminum • Weight, G.W. / N.W.: 1136 lbs/ 880 lbs • Max Load: 800 lbs |
DIMENSION INFORMATION |
|
| • Wheelbase: 63” • OA L x W x H: 108”x54”x74” |
• Seat Height: 33” • Min Ground Clearance: 11” |
KEY FEATURES |
|
| • Equipped with rear flip seat with extended hard roof top. Can be used as a neighborhood golf cart to carry up to 4 persons. • Equipped with H/L gear, low gear mode has 40% better climbing ability than the non H/L version & can climb up to 30 degree slopes with ease. • Air and oil cooled high performance 177.3 cc GY6 engine with internal reverse set up, with rear shaft direct drive, more reliable power transmission, higher transmission efficiency; • Four-wheel independent suspension for much better driving experience • Heavy duty frame, net weight 880 lbs, max load 800 lbs for 4 adult with flip seat • Digital dashboard • LED Hi/Lo head light • Rear view side mirrors • Sporting steering wheel • Turn signals • Safety harness seatbelt • Big dual purpose tires: F / R: 24 x 8-12 / 24 x 8-12 • Polished aluminum wheels • Extended Hard top • Adjustable heavy duty front and rear shock absorber • Rack and pinion steering wheel • Front and rear hydraulic disc brake • Large gas tank • Horn |
|
