Engine Information

·         EPA Certificated

·         Engine Type: 4-stroke, single cylinder, air and oil cooled

·         Displacement: 177.3cc

·         Compression Ratio: 8.8:1

·         Max HP: 9.5HP

·         Bore & Stroke: 62.5X57.8 mm

·         Max Torque and Crankshaft Speed: 11.0/4500 N.m/(RPM)

·         Nominal Power and Crankshaft Speed: 6.5/6500 kw/(RPM)

·         Max Speed: 25mph

·         Climbing Ability: 30 degrees

·         Ignition: C.D.I

·         Starting System: Electric

·         Battery: 12V 9Ah

·         Carburetor Brand: Deli

·         Engine Oil: SAE 15W/40

General Information

·         Transmission: Auto, L-H-N-R

·         Drive Train: Shaft Drive; 2 WD:

·         Drive Mode: Rear Shaft Drive, Rear differential

·         Suspension, F/R: Front MacPherson, Rear Dual A-ARM

·         Brakes, F / R: Both hydraulic brakes, Disc

·         Tires, F / R:  24 x 8-12 / 24 x 8-12

·         Fuel Tank Capacity: 4.8 gallons

·         Wheels: Aluminum

·         Weight, Gross 1018lbs/ net 828 lbs

·         Max Load: 600 lbs

·         Dump Bed Capacity: 220 lbs

·         Towing Capacity: 200 lbs

Dimension Information

·         Wheelbase: 63”

·         OA L x W x H: 108”x54”x74”

·         Seat Height: 33”

·         Min Ground Clearance: 11”

·         Bump Bed: 26.4”X43.4”X9.5”
