description
ENGINE / DRIVE TRAIN
| Displacement: | 169cc |
| Type: | 4-Stroke (EFI) Electronic Fuel Injection Engine (OHC) with Ceramic-Coated Cylinder |
| Handling: | A.L.E.H - Anti-Lift Engine Hanger System |
| Horsepower: | 12.2 hp - 7500 RPM |
| Max Torque: | 9.21 lb/ft - 5500 RPM |
| Cooling System: | Air |
| Transmission: | C.V.T. |
| Clutch: | Auto Centrifugal Type |
| Drive: | Belt |
| Starter: | Electrical Starter |
| Ignition: | ECU |
| Spark Plug: | CR7HSA |
| Battery Capacity: | 12V 8.6Ah (Closed Type, Maintenance-Free Battery) |
| Top Speed: | 65+ mph |
CHASSIS / SUSPENSION / BRAKES
| Frame: | High Strength Steel |
| Front Suspension: | Telescopic Fork |
| Rear Suspension: | Adjustable Dual Shock |
| Front Brakes: | Disc (226 mm) with CBS - Combined Braking System |
| Rear Brakes: | Disc (220 mm) with CBS - Combined Braking System |
| Front Tires: | 110 / 70 -12 |
| Rear Tires: | 120 / 70 -12 |
| Wheel: | Aluminum |
CAPACIITIES / DIMENSIONS
| Weight Capacity: | 333 Lbs |
| Net Weight: | 266.8 Lbs |
| Fuel: | Unleaded (90 octane or higher) |
| Fuel Capacity: | 1.63 Gallons |
| Length: | 74.40" |
| Width: | 26.57" |
| Height: | 43.89" |
| Seat Height: | 29" |
| Wheelbase: | 51.37" |
| Age Recommendation: | 16+ |
ADDITIONAL INFO
| Government Certifications: | EPA & DOT Approved, C.A.R.B. Approved for CA |
| Warranty: | 24 Months Unlimited Miles with Tire to Tire Parts & Labor Warranty Assurance |
| MPG: | 89 MPG* |
| LED lights: | Front Day-time Running LED Light & Tail Lights |
| QC 2.0 USB Power Outlet: | In Front Glove Compartment |
| Top Case: | Color Match Top Case Available |
