description
There's nothing better for beginners than this TrailMaster MID XRS. Low maintenance and high level of fun for the rider, just simply fuel up and get ready to enjoy yourself.
The TrailMaster MID XRS has a strong and durable frame, double oil damped shock, hydraulic brakes, two wheel drive live axle, powered by a 196cc 6.5hp easy pull start engine. This model is designed to let you go up to 25 MPH and has a climb range of 12 degrees, which is perfect for most trails. The simple design will also give you a lot more flexibility when it comes to navigation as you'll be able to turn easier while still protecting you from overhead brush.
ENGINE INFORMATION |
|
| • Engine type: 4-stroke, single cylinder, air cooled • Displacement: 200cc • Max HP: 6.3hp/3600rpm • Max torque: 9.6 lb ft/2500rpm • Bore x stroke: 2.6 x 2.1 inches • Max speed: 25mph |
• Climbing ability: 12 degrees • Ignition: C.D.I • Starting system: Manual Pull Start • Battery: 12V 9Ah only by Electric Start • Carburetor brand: JF (RX) • Engine oil: SAE 15W-40 |
GENERAL INFORMATION |
|
| • Clutch: Automatic CVT • Driveline / Driving wheel: Chain / Dual wheel drive • Suspension, F / R: Double Oil Damped Shock • Brakes, Rear Hydraulic brake, Disc |
• Tires, F / R: 145/70-6 / 16x6-8 • Fuel capacity: 1 gal • Weight, G.W. / N.W.: 386 / 330 lbs • Max load: 400 lbs |
DIMENSION INFORMATION |
|
| • Wheelbase: 48.4 inches • OA L x W x H: 67x43.3x51.2 inches • Height to seat: 10.2 inches |
• Min ground clearance: 2.8 inches • Pedal to seat back distance: 31.5 to 34 |
KEY FEATURES |
|
| • 4 stroke 6.3HP OHV engine • Rack and pinion steering • Two wheel drive, live axle • Fully suspension front and rear |
• Safety belt • Adjustable pedal • Speed governor |
