description
STANDARD FEATURES
• 2" Frame mounted winch receiver
• Fully enclosed climate controlled cab
• Compact design with bench seating
• Middle and side mirrors
• HID/LED halo high/low head lights
• Steel front and rear A-Arm guards
• Electric/hydraulic dump bed
• AND MORE!
• 2" Frame mounted winch receiver
• Fully enclosed climate controlled cab
• Compact design with bench seating
• Middle and side mirrors
• HID/LED halo high/low head lights
• Steel front and rear A-Arm guards
• Electric/hydraulic dump bed
• AND MORE!
DIMENSIONS
• VEHICLE SIZE (L X W X H): 132.4 IN X 73.6 IN X 76.7 IN
• WHEELBASE: 91.5 IN
• GROUND CLEARANCE: 12.5 IN
• CARGO BED(L X W X H): 42.5 IN X 65.5 IN X 10.25 IN
• CARGO BED: HYDRAULIC PISTON DUMP
• TOWING CAPACITY: 1,500 LBS
• CARGO BED CAPACITY: 500 LBS
• FUEL CAPACITY: 12.7 GALLONS
• SEAT HEIGHT: 34.5 IN
• DRY WEIGHT: 2138 LBS
• WHEELBASE: 91.5 IN
• GROUND CLEARANCE: 12.5 IN
• CARGO BED(L X W X H): 42.5 IN X 65.5 IN X 10.25 IN
• CARGO BED: HYDRAULIC PISTON DUMP
• TOWING CAPACITY: 1,500 LBS
• CARGO BED CAPACITY: 500 LBS
• FUEL CAPACITY: 12.7 GALLONS
• SEAT HEIGHT: 34.5 IN
• DRY WEIGHT: 2138 LBS
4 STROKE 2 CYLINDER V-TWIN
ENGINE TYPE: FOUR STROKE 2 CYLINDER
DISPLACEMENT: 1000CC
HORSEPOWER: 72 HP
COOLING: LIQUID COOLED
TRANSMISSION/FINAL DRIVE: AUTOMATIC CVT P/R/N/L/H, SHAFT DRIVE
DRIVE SYSTEM: 2WD/4WD, LOCKING DIFFERENTIAL
FUEL SYSTEM: ELECTRONIC FUEL INJECTION (EFI)
DISPLACEMENT: 1000CC
HORSEPOWER: 72 HP
COOLING: LIQUID COOLED
TRANSMISSION/FINAL DRIVE: AUTOMATIC CVT P/R/N/L/H, SHAFT DRIVE
DRIVE SYSTEM: 2WD/4WD, LOCKING DIFFERENTIAL
FUEL SYSTEM: ELECTRONIC FUEL INJECTION (EFI)
CHASSIS
• FRONT SUSPENSION: INDEPENDENT DUAL A-ARM
• REAR SUSPENSION: INDEPENDENT DUAL A-ARM
• FRONT TIRES: AT 27X 9-14
• REAR TIRES: AT 27X 11-14
• FRONT BRAKES: DUAL VENTILATED HYDRAULIC DISK BRAKES
• REAR BRAKES: DUAL VENTILATED HYDRAULIC DISK BRAKES
• REAR SUSPENSION: INDEPENDENT DUAL A-ARM
• FRONT TIRES: AT 27X 9-14
• REAR TIRES: AT 27X 11-14
• FRONT BRAKES: DUAL VENTILATED HYDRAULIC DISK BRAKES
• REAR BRAKES: DUAL VENTILATED HYDRAULIC DISK BRAKES
ADDITIONAL FEATURES
ELECTRONIC POWER STEERING
WARRANTY: 1 YEAR PARTS & LABOR
BATTERY: 12V 35AMP
ASSEMBLED IN TEXAS, USA
INSTRUMENTATION: DIGITAL DISPLAY, SPEEDOMETER,
ODOMETER, TACHOMETER, HOUR METER, GEAR INDICATOR,
4WD INDICATOR, DIFFERENTIAL LOCK INDICATOR,
TRIP METER, HEADLIGHTS (HIGH/LOW), TURN SIGNALS,
FUEL GAUGE, HI-TEMP
WARRANTY: 1 YEAR PARTS & LABOR
BATTERY: 12V 35AMP
ASSEMBLED IN TEXAS, USA
INSTRUMENTATION: DIGITAL DISPLAY, SPEEDOMETER,
ODOMETER, TACHOMETER, HOUR METER, GEAR INDICATOR,
4WD INDICATOR, DIFFERENTIAL LOCK INDICATOR,
TRIP METER, HEADLIGHTS (HIGH/LOW), TURN SIGNALS,
FUEL GAUGE, HI-TEMP
HVAC
• VORTEX TYPE AIR-CONDITIONING COMPRESSOR
• REFRIGERATION DISPLACEMENT 66 ML (ML) / R (ROTATION)
• COMPRESSOR SPEED: 1800R (TRANSFER) - 7200R (REVOLUTION)
• COMPRESSOR POWER 48KW (4A)
• REFRIGERATION DISPLACEMENT 66 ML (ML) / R (ROTATION)
• COMPRESSOR SPEED: 1800R (TRANSFER) - 7200R (REVOLUTION)
• COMPRESSOR POWER 48KW (4A)
