POWER

Engine Type: NC298, Single Cylinder, 4-Stroke, 4-Valve, Liquid Cooled, SOHC, Balance Shaft

Displacement: 298 ml

Max Power: 23KW / 9000rpm - 31Hp

Bore x Stroke: 82 x 53.6 mm

Lubrication: Pressure and Splash

Shift Type: Wet multi disc clutch, International Gear Pattern, 6-Speed

Start Type: Electric & Kick Start

Carburetor: PWK36 Competition Carb.

Ignition: Digital CDI

Drive Train: #520 Chain, FT: 13T/RR: 51T Sprocket

PERFORMANCE

Front Fork: Φ54*Φ60-940mm Inverted Hydraulic Dual Adjustable Forks, 300mm Travel

Rear Shock: 482mm Dual Adjustable Shock with Ballonet, 120mm Travel

Front Wheel: 7116 Aluminum Rim, Gravity Cast Hub, FT: 1.6 x 21

Rear Wheel: 7116 Aluminum Rim, Gravity Cast Hub, RR: 2.15 x 18

Front Tires: 80/100-21

Rear Tires: 110/100-18

Front Brake: Dual Piston Caliper, 270mm Disc

Rear Brake: Single Piston Caliper, 240mm Disc

DETAILS

Frame: Zuumav Aluminum Perimeter Frame

Swing-Arm: Forged Aluminum Swingarm,L=590mm

Handle Bar: Tapered Aluminum #7075

Overall Size: 2170x800x1310 mm

Packing Size: 1715x445x860mm

Wheel Base: 1490 mm

Seat Height: 950 mm

Ground Clearance: 300 mm

Fuel Capacity: 6.5 L / 1.72 Gal.

N.W: 115KG

G.W: 145KG
