Engine type
|
V-Two-cylinder, 4-stroke,SOHC, water cooling
|
|
Number of valves
|
8(mechanical adjustment)
|
|
Cylinder diameter
|
91 mm
|
|
Piston stroke
|
75mm
|
|
Displacement
|
976cm3
|
|
Compression ratio
|
10.3:1
|
|
Maximum power
|
53KW/6500rpm
|
|
Transmission type
|
CVT
|
|
Gearbox type
|
Dual range(H/L) with park, neutral and reverse
|
|
Overall length
|
3358mm
|
|
Overall width
|
1913mm
|
|
Overall height
|
1947mm
|
|
Cargo box
|
1076×1561×260(mm)
|
|
Front gauge
|
1395
|
|
Rear gauge
|
1358
|
|
Wheel base
|
2322
|
|
Brake type
|
Dual disc brake
|
|
Tire size（Front/Rear）
|
28×10-14/28×10-14
|
|
Drive train
|
Shaft driven/single auto-lock differential
|
|
Suspension type
|
Double wishbone independent suspension
|
|
Climbing ability
|
≥40°
|
|
Approach angle
|
69°
|
|
Departure angle
|
75°
|
|
Ground clearance
|
327mm
|
