Model Number:

ATV-3200S/ATV-EV3200S|

Engine Type:

Single Cylinder, 4-Stroke, Air-Cooled

Displacement:

168.9cc

Max Torque:

10.2 N-m/5000 г/min (N.m/t/min)

Max Power:

7.6 kW/7000 г/min(kW/r/min)

Bore Stroke:

61 × 57.8mm

Ignition:

CDI

Starting System:

Electric

Battery:

12V, 4Ah

Clutch:

Automatic

Transmission:

Chain, Rear Wheel Drive

Brakes Front/Rear:

Hydraulic Disc

Fuel Capacity:

1.35 gallons / 5.1L

Maximum Weight Capacity:

220 lbs / 100 kg (rider, all cargo and accessories)

Wheelbase:

1,195mm

Dimensions:

1,900 x 1,120 x 1,160mm

Height to Seat:

440mm

Min. Ground Clearance:

130mm
