description
Engine Information
EPA and CARB certificated
Engine type: 4-stroke, single cylinder, water- cooled
Displacement: 300cc
Max HP: 18hp/6500rpm
Max torque: 16 lb ft/5000rpm
Bore x stroke: 2.85x2.63 inches
Ignition: ECU
Starting system: Electric
Battery: 12V 10Ah
Engine oil: SAE 15W-40
General Information
Clutch: Automatic CVT with reverse
Driveline / Driving wheel: Chain / Dual wheel drive
Suspension F / R: Independent Dual A-arm / Swing Arm, Double Oil Damped Shock
Brakes, F / R: Both hydraulic brakes, Disc
Tires, F / R: 22x7-10 / 22x10-10
Fuel capacity: 1.75 gal
Weight, G.W. / N.W.: 800 / 617 lbs
Max load: 500 lbs
Dimension Information
Wheelbase: 72 inches
OA L x W x H: 98x50x60 inches
Height to seat: 21 inches
Min ground clearance: 6.3 inches
