ENGINE / DRIVE TRAIN
| Displacement: | 124.6 cc |
| Type: | 4 Stroke Single Cylinder with Ceramic Coating Cylinder Technology |
| Compression Ratio: | 9.6:1 |
| Horsepower: | 8.38 HP - 7500 RPM |
| Max Torque: | 6.14 lb/ft - 6500 RPM |
| Cooling System: | Air Cooled |
| Transmission: | C.V.T. |
| Clutch: | Auto Centrifugal Type |
| Drive: | Belt |
| Starter: | Electrical Starter |
| Ignition: | CDI |
| Spark Plug: | Torch A7RC |
| Battery Capacity: | 12V 6Ah (closed type, maintenance-free) |
| Top Speed: | 59 mph |
CHASSIS / SUSPENSION / BRAKES
| Frame: | High Strength Steel |
| Front Suspension: | Telescopic Fork |
| Rear Suspension: | Unit Swing |
| Front Brakes: | Disc (180 mm) |
| Rear Brakes: | Drum (130 mm) |
| Front Tires: | 110/70 - 12 |
| Rear Tires: | 120/70 - 12 |
| Wheel: | Aluminum |
CAPACIITIES / DIMENSIONS
| Weight Capacity: | 333 Lbs |
| Net Weight: | 220 Lbs |
| Fuel: | Unleaded (90 octane or higher) |
| Fuel Capacity: | 1.18 Gallons |
| Ground Clearance: | 7.5 in |
| Length: | 76.37 in |
| Width: | 34.25 |
| Height: | 44.88 |
| Seat Height: | 30 in |
| Wheelbase: | 51.57 in |
| Age Recommendation: | 16+ |
ADDITIONAL INFO
| Government Certifications: | EPA & DOT Approved, C.A.R.B. Approved for CA |
| Warranty: | Build by SYM with 24 months unlimited miles with tire to tire parts and labor warranty assurance |
| MPG: | 90 MPG* |
