ENGINE / DRIVE TRAIN
| Displacement: | 124 cc |
| Type: | 4 Stroke Single Cylinder with Ceramic Coating Cylinder Technology |
| Compression Ratio: | 9.6:1 |
| Horsepower: | 8.38 HP - 7500 RPM |
| Max Torque: | 6.14 lb/ft - 7000 RPM |
| Cooling System: | Air Cooled |
| Transmission: | C.V.T. |
| Clutch: | Auto Centrifugal Type |
| Drive: | Belt |
| Starter: | Electrical Starter |
| Ignition: | CDI |
| Spark Plug: | Torch A7RC |
| Battery Capacity: | 12V 6Ah (closed type, maintenance-free) |
| Top Speed: | 59 mph |
CHASSIS / SUSPENSION / BRAKES
| Frame: | High Strength Steel |
| Front Suspension: | Telescopic Fork |
| Rear Suspension: | Unit Swing |
| Front Brakes: | Disc (190 mm) with Sport Style Wave Rotor |
| Rear Brakes: | Drum (130 mm) |
| Front Tires: | 120/70 - 12 Knobby Tire |
| Rear Tires: | 130/70 - 12 Knobby Tire |
| Wheel: | Aluminum |
CAPACIITIES / DIMENSIONS
| Weight Capacity: | 333 Lbs |
| Net Weight: | 218.3 Lbs |
| Fuel: | Unleaded (90 octane or higher) |
| Fuel Capacity: | 1.37 Gallons |
| Ground Clearance: | 8.1 in |
| Length: | 75 in |
| Width: | 27.16 in |
| Height: | 48.74 in |
| Seat Height: | 31 in |
| Wheelbase: | 52.16 in |
| Age Recommendation: | 16+ |
ADDITIONAL INFO
| Government Certifications: | EPA & DOT Approved, C.A.R.B. Approved for CA |
| Warranty: | Build by SYM with 24 months unlimited miles with tire to tire parts and labor warranty assurance |
| MPG: | 90 MPG* |
| Instrument Panel: | LCD display with the ability 3 colors shifting LED backlight |
| Daytime Running Lights: | LED Daytime Running Lights |
| Seat: | Two-Tone Material Seat with Red Stitch |
| Brake: | Front Sport Style Disc Brake with Wave Rotor |
| Others: | Aluminum Handlebar End Caps & Hands Guards |
