description
|
ENGINE INFORMATION |
|
| • EPA certificated • Engine type: 4-stroke, single cylinder, air cooled • Displacement: 168.9cc • Max HP: 11.1hp/8000rpm • Max torque: 8.1 lb ft/6000rpm • Bore x stroke: 2.4x2.28 inches |
• Climbing ability: 12 degrees • Ignition: C.D.I • Starting system: Electric • Battery: 12V 10Ah • Carburetor brand: Deli (Vacuum film) • Engine oil: SAE 15W-40 |
|
GENERAL INFORMATION |
|
| • Clutch: Automatic CTV with reverse • Driveline / Driving wheel: Chain / Dual wheel drive • Suspension F / R: Double A-arm / swing-arm • Brakes, F / R: Both hydraulic brakes, Disc |
• Tires, F / R: 20x7-8 / 21x10-10 • Wheel: Steel • Fuel capacity: 2.25 gal • Weight, G.W. / N.W.: 573 / 485 lbs • Max load: 500 lbs |
|
DIMENSION INFORMATION |
|
| • Wheelbase: 59 inches • OA L x W x H: 85x53.1x57.5 inches • Height to seat: 13.8 inches |
• Min ground clearance: 6.7” • Pedal to seat back distance: 41” to 46” |
|
KEY FEATURES |
|
| • Alloy wheels with 22X8-10 front and 22X10-10 rear aggressive tread tires • Top LED light bar • 4MM high quality windshield • Nitrogen adjustable front and rear shock • Upgraded racing seat belt • Digital speedometer/odometer • Aluminum side mirrors • Turn signals • Sporting steering wheel • Stylish design • Exciting graphics • Five-point safety harness • Electric start with kill switch • Fully automatic with reverse, high performance 150cc GY6 engine with internal F-N-R • Adjustable steering wheel • Individual sports seats • Polished stainless steel muffler • LED headlight • Bikini sunshade top • Adjustable driver seat: pedal to seat back adjustable from 41” to 46” • Central rear view mirror • Rack and pinion steering wheel • Front and rear hydraulic disc brake • 4-point rear swing arm • Parking brake • 4-wheel stylish fenders • Trailer hitch • Large rear utility rack • Large gas tank |
