description
For scooter enthusiasts who don't want a traditional step-through style scooter, check out the new AR-50! It has the heart of a motorcycle and the soul of a scooter! The AR-50 includes a digital speedometer and an exhaust with a throaty sound. It comes standard with a 49.5cc 4-stroke engine with automatic twist-and-go transmission, making it perfect for first-time riders!br>The AR-50 comes fully loaded with many upgraded features
Engine Specifications
Engine: 139QMB
Cooling: Air cooled
Bore x Stroke: 39mm x 41.5mm
Compression Ratio: 10.4:1
Horsepower: 1.8hp @ 8,000RPM
Ignition: CDI
Starter: Electric/Kick
Engine Oil: SJ10W-40
Transmission: CVT
Spark Plug: CR7HSA
Belt: 729-17.5
Scooter Specifications
Front Suspension: Hydraulic Straight
Rear Suspension: Single Hydraulic
Front Tire: 120/70-12
Rear Tire: 120/70-12
Brakes (Front/Rear): Disc / Drum
Dimensions: 70.3" x 29.5" x 59.0"
Seat Height: 31"
Fuel Capacity: 1.45gal
Load Capacity: 300lbs
Gross Weight: 200lbs
Battery: 12V/7AH
Headlight: Halogen
| ENGINE | 49cc |
|---|---|
| Type | 49cc, Air-cooled, Single Cylinder, 4-Stroke |
| Bore x Stroke | No |
| Compression Ratio | 10.4:1 |
| Fuel Delivery | Carburetor |
| Transmission | Automatic CVT |
| Ignition System | CDI |
| Starting System | Electric & Kick |
| Max Speed | 30 mph |
| CHASSIS | DETAILS |
| Front Suspension | Straight |
| Rear Suspension | Single |
| Brakes (Front/Rear) | Disc/Drum |
| Tires (Front/Rear) | 120/70-12; 120/70-12 |
| Swingarm | No |
| Dimensions (in.) | 77 x 49 x 62 |
| L x W x H | No |
| Wheelbase | No |
| Seat Height | No |
| Ground Clearance | No |
| Weight | 200 lbs |
| Fuel Capacity | 1.6 gal |
