description

Model RX36C
ENGINE Single cylinder air cooled four strokes
DISPLACEMENT  223CC
BORE/STROKE  65.5mm×66.2mm
COMPRESSION RATIO  9.61
MAX.POWER 12kW/7500r/min
MAX.TORQUE 17.5Nm/5500r/min
STARTER Electric/Kick start
TRANSMISSION Chain transmission
GEAR 5 gears
INTAKING MODE Overhead cam
CARBURETOR PZ30
IGNITION CDI
HANDLEBAR Shovel 22mm
FRONT SUSPENSION  Non-adjustable damping
REAR SUSPENSION Non-adjustable damping
FRONT TIRES 110/70-17
REAR TIRES  130/70-17
MAIN SILENCER stainless steel
STEERING HEAD ANGLE  ≤42°
WHEELBASE  1430mm
GROUND CLEARANCE 220mm
FUEL TANK CONTENTS 6.2L
NET WEIGHT  125kg
L*W*H (length * width * height) 2080mm×830mm×1460mm
