description
|
Engine Information |
|
| EPA certificated | |
| Engine type: | 4-stroke, single cylinder, air cooled |
| Displacement: |
200cc |
| Max HP: |
6.3hp/3600rpm |
| Max torque: |
9.6 lb ft/2500rpm |
| Bore x stroke: |
2.6 x 2.1 inches |
| Climbing ability: |
12 degrees |
|
Engine oil: |
SG15W-40 |
| Ignition: |
C.D.I |
| Starting system: |
Electric / Pull backup |
|
Battery: |
12V 9Ah |
|
Carburetor brand: |
JF (RX) |
|
|
|
| General Information | |
|
Clutch: |
Automatic CTV |
|
Driveline / Driving wheel: |
Chain / Dual wheel drive |
|
Suspension, F / R: |
Double A-arm / swing-arm(Double Oil Damped Shock) |
|
Brakes, F / R: |
No / Hydraulic brake, Disc |
|
Tires, F / R: |
16x6-8 / 16x7-8 |
|
Fuel capacity: |
1 gal |
|
Weight, G.W. / N.W.: |
386 /330 lbs |
|
Max load: |
400 lbs |
|
Dimension Information |
|
|
Wheelbase: |
48.4 inches |
|
OA L x W x H: |
67x43.3x51.2 inches |
|
Height to seat: |
10.2 inches |
|
Min ground clearance: |
2.8 inches |
| Pedal to seat back distance: | 31.5'' to 37'' |
|
Shipping information: |
54 units/40HQ |
