ENGINE INFORMATION |
|
• EPA Certificated |
• Max Power and Crankshaft Speed: 19/6500 kw/(RPM) • Max Speed: 35mph • Climbing Ability: 30 degrees • Fuel: EFI • Starting System: Electric • Battery: 12V 30Ah • Engine Oil: SAE 15W/40 |
GENERAL INFORMATION |
|
• Transmission: Automatic, L-H-N-R, with locking differential • Drive Train: Shaft Drive; 4 WD: • Drive Mode: Four Wheel Drive, Front and Rear differential with lock; Balanced crank shaft engine • Suspension, F / R: Front MacPherson, Rear Dual A-ARM • Brakes, F / R: Both hydraulic brakes, Disc |
• Tires, F / R: 24 x 8-12 / 24 x 8-12 • Fuel Tank Capacity: 7.93 gallons • Wheels: Aluminum • Weight, G.W. / N.W. 1760 lbs/ 1320 lbs • Max Load: 1000 lbs • Dump Bed Capacity: 330 lbs • Towing Capacity: 1000 lbs |
DIMENSION INFORMATION |
|
• Wheelbase: 95.5” • OA L x W x H: 121.7”x58.27”x76.4” • Seat Height: 33” |
• Min Ground Clearance: 11” • Bump Bed Size: 26.4”X43.4”X13.2” |
KEY FEATURES |
|
1. Unrivalled four seats/six seats in small and medium displacement UTV 2. Equipped with both rear flip seat and utility dump bed, interchangeable within a few minutes; Can be used as a neighborhood golf cart to carry up to 6 adults or as a utility vehicle with heavy duty dump bed & still carrying up to 4 adults 3. Four Wheel Drive, Front and Rear locking differential; Balance crank shaft engine 4. Equipped with H/L gear, can climb up to 30 degree slopes with ease with full capacity 5. Liquid cooled high performance 390.8 cc 25.8 HP engine with internal reverse set up, with rear shaft direct drive, more reliable power transmission, higher transmission efficiency; 6. Four-wheel independent suspension for much better driving experience 7. Heavy duty frame, net weight 1320 lbs, max load 1000 lbs for 6 adults with flip seat or 660 lbs with dump bed(330 lbs load capacity on dump bed) 8. EFI & Large gas tank 9. Digital speedometer/odometer 10.LED Hi/Lo beam head light 11.Rear view side mirrors 12.Sporting steering wheel 13.Turn signals 14.Safety harness seatbelt 15.Big dual purpose tires: F / R: 24 x 8-12 / 24 x 8-12 16.Polished aluminum wheels 17.Hard top & Horn 18.Adjustable heavy duty front and rear shock absorber 19.Rack and pinion steering 20.Front and rear hydraulic disc brake |
