description

Engine Displacement: 196cc, 6.5 HP

Starting: Recoil Cord

Spark Plug Type: Torch - F7RTC

Cooling: Air cooled

Ignition Type T.C.I

Cylinder head config.: OHV

Number of Cylinder: Single

Combustion Cycle: 4-stroke

Bore and Stroke: 68 x 54mm

Compression Ratio: 8.5:1

Rated Power: 4.7kw @ 3600rpm

Rated Torque: 13.5Nm @ 2500rpm

Idle Speed 1500 ± 100 rpm

Top Speed 25mph

Drive System Type: Chain Drive

Gear Ratio: Centrifugal clutch

Rear Brakes Mechanical Disc

Tires: Front Tire Size AT145/70-6; Rear Tire Size AT145/70-6

Fuel Gas Tank Capacity: 0.81gal.

Fuel type Unleaded 87 octane or higher

Oil Capacity .53qt. (.5L)

Oil Type SAE 10W-40



Dimensions and Weights

Length x Width x Height: 51.2” x 25.6”x 35.4”

Seat Height: 25.2”

Ground Clearance: 6”

Vehicle Net Weight: 103lbs

Weight Capacity: 175lbs

Crate dimension: 53”x23”x18”

Shipping Weight: 130lbs (With pallet: 170lbs)
