description
Vehicle specification
|
Overall Vehicle Size (L x W x H) |
83x46x 50 in |
|
Ground Clearance (inch) |
7.2 in |
|
Wheelbase (inch) |
51 in |
|
Weight with full equipment |
618 lbs |
|
Front / Rear Brakes |
Two sides hydraulic disc |
|
Parking Brake |
Front / Rear hand brake,Foot brake |
|
Front Tires |
AT24X8-12 |
|
Rear Tires |
AT24X11-10 |
|
Front Suspension |
McPherson independent suspension |
|
Rear Suspension |
Socket centering structure |
|
Fuel Capacity |
3.8 gallons |
Engine Specification
|
Engine model |
LH173MN |
|
Engine Type |
Carburetor, 4 Stroke, Single Cylinder, SOHC, Water Cooling |
|
Bore & stroke |
2.85*2.63 in |
|
Volumetric Compression Ratio |
10.3:1 |
|
Displacement |
257cc |
|
Drive System Type |
2WD or 4WD |
|
Ignition type |
T.C.I |
|
Start type |
Electric |
|
Maximum power (Kw /r/min) |
22 HP @ 6500 RPM |
