description
SPECIFICATION
PERFORMANCE
Maximum Speed
22 mph (35 kph)
Climbing Angle
≥1 2 °
Sideslip
≤5m/km
Turning Radius
1.5 m
Load Capacity
198 lb (90 kg)
ENGINE
Engine Model
168G General Purpose Engine
Engine Capacity
196CC
Start Method
Pull Back Push Start
Clutch
Automatic
Engine Transmission Mode
Chain Drive
Engine Torque
11 N, M/ 2500 r/min
Engine Oil Grade
SF 15W-40
Engine Oil Capacity
0.6L
Maximum Engine Power
4.0 kw/ 3600 r/min
CHASSIS
Fuel Tank Capacity
4L
Wheel Model
19x7-8
Shock Absorber
Front - 580 mm
Braking Method
Hand Brake/Rear Brake
Braking Distance
30km/h ≤ 7 m
DIMENSION
Gross Weight
192 lb (87 kg)
Vehicle Length
63.5 in (1615 mm)
Vehicle Width
29.5 in (750 mm)
Vehicle Height
36 in (915 mm)
Packaging Carton
1415x455x770
