Engine Information
EPA certificated
Engine type: 4-stroke, single cylinder, air cooled, Horizontal OHV Engine
Displacement: 208cc, 7.5HP
Max HP: 7.5hp/3600rpm
Max torque: 8 lb ft/2800rpm
Bore x stroke: 2.76x2.13 inches
Max speed: 32 mph
Climbing ability: 12 degrees
Ignition: C.D.I
Starting system: Electric or Pull
Battery: 12V 10Ah
Carburetor brand: JF210N.9.1C
Engine oil: SAE 15W-40
General Information
Clutch: Automatic torque converter CVT with reverse
Driveline / Driving wheel: Chain / Dual wheel drive
Suspension F / R: Double A-arm / swing-arm
Brake: Rear disc
Tires, F / R: 18X7-8 / 18X7-8
Wheel: Steel
Fuel capacity: 1 gal
Weight, G.W. / N.W.: 485 / 400 lbs
Max load: 400 lbs
Dimension Information
Wheelbase: 57 inches
OA L x W x H: 79x51x56.3 inches
Height to seat: 15.7 inches
Min ground clearance: 4 inches
Pedal to seat back distance: 32” to 38”
Packing size: 79X45X26 inches
Sporty stylish design
Articulating rear suspension equipped with anti-slip pull belts, much harder to roll over comparing to other rear solid axle machines
Youth/Adult size
Adjustable driver seat: pedal to seat back adjustable from 32” to 39”, fits person up to 5’8”
Pull cord kill switch
4 point safety seat belt
Manual choke
LED headlight and turn signal
Electric start with pull start backup
Fully automatic with reverse, 7.5 HP horizontal OHV engine
Individual sports seats
Bikini sunshade top
Rack and pinion steering wheel
Hydraulic rear disc brake
Max speed 32 m/h
Parking brake
Large rear utility rack
