Engine Information

EPA certificated

Engine type: 4-stroke, single cylinder, air cooled

Displacement: 168.9cc

Max HP: 11.1hp/8000rpm

Max torque: 8.1 lb ft/6000rpm

Bore x stroke: 2.4x2.28 inches

Max speed: 35 mph

Climbing ability: 20-25 degrees

Ignition: C.D.I (for carburetor) & ECU (for EFI version)

Starting system: Electric

Battery: 12V 10Ah

Engine oil: SAE 15W-40

General Information

Clutch: Automatic CTV with reverse

Driveline / Driving wheel: Chain / Dual wheel drive

Suspension F / R: Independent Dual A-arm / Double Oil Damped Shock

Brakes, F / R: Both hydraulic brakes, Disc

Tires, F / R: 22x7-10 / 22x10-10

Fuel capacity: 1.75 gal

Weight, G.W. / N.W.: 750 / 578 lbs

Max load: 500 lbs

Dimension Information

Wheelbase: 72 inches

OA L x W x H: 98x48x60 inches

Crate size: 90X54X33 inches

Height to seat: 21 inches

Min ground clearance: 6.3 inches
