description
| Model Number: | ATV-3125B2 |
| Engine Type: | Single Cylinder, 4-Stroke, Air-Cooled |
| Displacement: | 110cc |
| Max Torque: | 6.9N.m/6,500 ± 500r/min (N.m/r/min) |
| Max Power: | 5.5kW/8,500 ± 500r/min (kW/r/min) |
| Bore Stroke: | 52.4 x 55.5mm |
| Ignition: | CDI |
| Starting System: | Electric |
| Battery: | 12V, 5Ah |
| Clutch: | Fully-Automatic |
| Transmission: | Chain, Rear Wheel Drive |
| Brakes Front/Rear: | Hydraulic Disc |
| Tires Front/Rear: | 19 x 7 – 8 / 18 x 9.5 – 8 |
| Fuel Capacity: | 0.54 gallons / 2.06L |
| Maximum Weight Capacity: | 165 lbs / 75 kg (rider, all cargo and accessories) |
| Wheelbase: | 1035mm |
| Dimensions: | 1,625 x 990 x 1,040mm |
| Height to Seat: | 730mm |
| Min. Ground Clearance: | 135mm |
